SANY SY35U excavator

technical specifications

Mass
3.78 t
Operating weight
3,780 kg
Bucket volume
0.12 m³
Boom length
2.54 m
Handle length
1.4 m
Digging force (bucket)
30.4 kN
Digging force (handle)
18.2 kN
Movement speed
4.4-2.4 km/h
Traction force
36.8 kN
Turning speed
9 rpm
Pad width (standard)
300 mm
Track length
2 115 mm
Soil pressure
32 kPa
Max. digging height
4,855 mm
Max. unloading height
3,460 mm
Max. digging depth
3 105 mm
Max. digging depth (vertical wall)
2,700 mm
Max. digging radius (at ground level)
5,465 mm
Transport length
4,915 mm
Transport width
1,720 mm
Transport height
2 515mm
Model
Yanmar 3TNV88F
Power
18.2 kW
Torque
90 Nm
Emission standard
Tier 4
Engine displacement
1.64 l
Fuel tank
40 l

Advantages of this model

High performance

High power ensures reliability in difficult operating conditions.

High reliability

Load-Sensitive Flow Distribution System: Senses micro-changes in load and adjusts flow and pressure in real time; optimized master valve core for perfect synergy between actuators and precise control.

High adaptability to different situations

Interchangeable steel track/rubber track. Cab or canopy of your choice.
